Material: PE100
Pressure rating: SDR9/PN20, SDR11/PN16, SDR13.6/PN12.5, SDR17/PN10,
SDR21/PN8, SDR26/PN6, SDR33/PN5
Size: dn20-1200mm
Standard: ISO4427-2, EN12201-2, AS/NZS 4130, BS 6920, GB/T 13663
Color: black color with blue strips or blue color for water
Form supplied:
* Pipe diameter dn20-dn63mm in 50-200m coil length
* Pipe diameter dn20-dn1200mm in 5.8 or 11.8 meters straight length
* Other forms are also available upon request
Non-toxic: no heavy metal additives, would not be covered with dirt or
contaminated by bacterium, sanitary, no secondary pollution
* Corrosion resistance: unaffected by chemical matters and electron chemical
matters which cause corrosion in metals.
* High flow capacity: smooth interior walls and low abrasion resistance result low
flow resistance and high flow capacity.
* Excellent Flexibility: can be supplied in coil form, fewer fittings required and
lower cost in installation.
* High impact and breakage resistance.
* Excellence UV resistance: black color HDPE pipe includes 2-2.5% black carbon
content, allow the pipe can be exposed outdoor.
* Easy installation: light weight, easy to transport and handle friendly.
* Long service life: can work for more than 50 years under proper use.
* Various joint availability: thermal butt fusion, electro fusion or mechanical joint
| Item | Technical Index |
|---|---|
|
Density (g/cm³) |
0.941~ 0.965 |
|
Black Carbon Content |
2 ~ 2.5% |
|
Vica Softening Point (℃) |
≥126 |
|
Melt Flow Rate, 190℃, 5kg (g/10min) |
0.2 ~ 1.4 |
|
Melt Flow Rate, 190℃, 5kg (g/10min) |
0.2 ~ 1.4 |
|
Longitudinal Shrinking Rate |
≤3% |
|
Elastic Modulus (Mpa) |
600 ~ 900
|
|
Coefficient Of Linear Expansion (mm/m℃) |
0.16 ~ 0.20 |
|
Oxidation Induced Time , 200℃ (min) |
≥20 |
